THE COMPETITION ISN'T GOING TO LIKE YOU MUCH.

Our world-leading IA 2.0 platform fully kitted out with the amazing SRAM Force eTap AXS groupset and Zipp carbon wheels. This race rig will put your competitors in the rearview mirror, marveling at your speed and the wind-cutting profile your propel down the course. Featuring the proven performance of SRAM's AXS technology and the agility Zipp wheels deliver, get ready to fly.

SPECIFICATIONS

FRAMESET

• FRAMEFelt IA 2.0, UHC Ultimate + TeXtreme carbon
• FORKFelt IntegratedAero Disc 2.0, UHC Ultimate + TeXtreme carbon

BRAKES & DRIVETRAIN

• FRONT BRAKESRAM S-900 AERO HRD, 2-piston, Hydraulic disc brake
• FRONT BRAKE ROTORSRAM PaceLine XR, 140 mm, Center lock
• REAR BRAKESRAM S-900 AERO HRD, 2-piston, Hydraulic disc brake
• REAR BRAKE ROTORSRAM Paceline XR, 140 mm, Center lock
• BRAKE LEVERSRAM S-900 AERO HRD
• REAR DERAILLEURSRAM Force eTap AXS, 12-S
• CASSETTESRAM XG-1270, 10-33 T
• CHAINSRAM Force
• CRANKSETSRAM Force 1 AXS Power Meter, 48 T
• SHIFT LEVERSRAM eTap MultiClics

WHEELS

• WHEELSETZIPP 404/808 Firecrest Carbon
• TIREContinental Grand Prix 5000

COCKPIT

• HEADSETIS (IS-2)
• HANDLEBARAerobar-Stem-Combination: Felt Dagger Direct 2.0 ASC / Extensions: Devox Ergomod | carbon fiber
• BAR TAPEFelt EVA arm pads with anti-microbial cover and Felt Gel tape
• SADDLEISM PS1.0, Satin Steel
• SEAT POSTFelt Aero TRI IL 2.0 VM

ADDITIONAL INFORMATION

• PERMISSIBLE TOTAL WEIGHT129kg
• TRAILER APPROVALNo trailer approval



SIZE GUIDE

	47	48	51	54	56	58
RIDER HEIGHT	152.4 - 167.6 cm 5’0” - 5’5”	152.4 - 167.6 cm 5’0” - 5’5”	167.6 - 172.7 cm 5’5” - 5’8”	172.7 - 180.3 cm 5’8” - 5’11”	180.3 - 187.9 cm 5’11” - 6’2”	187.9 - 195.5 cm 6’2” - 6’5”
RIDER INSEAM Measured from crotch to floor.	70.8 - 74.4 cm 27.9” - 29.3”	70.8 - 74.4 cm 27.9” - 29.3”	74.4 - 77.9 cm 29.3” - 30.7”	77.9 - 83.0 cm 30.7” - 32.7”	83.0 - 85.8 cm 32.7” - 33.8”	85.8 - 88.9 cm 32.7” - 35.0”

GEOMETRY

	48	51	54	56	58
(A) Top Tube Length	468 mm	486 mm	510 mm	541 mm	573 mm
(B) Seat Tube Length	496 mm	525 mm	546 mm	571 mm	598 mm
(C) Seat Tube Angle	79.5 °	79 °	78.5 °	78 °	77.5 °
(D) Head Tube Length	67.5 mm	96 mm	111 mm	136 mm	163 mm
(E) Steering Angle	71.5 °	71.5 °	72 °	72 °	72 °
(F) Chain Stay Length	405 mm	405 mm	405 mm	405 mm	405 mm
(G) Wheel Base	970 mm	987 mm	1000 mm	1029 mm	1058 mm
(H) Standover Height	735 mm	749 mm	765 mm	779 mm	793 mm
(I) BB-Drop	72 mm	72 mm	72 mm	72 mm	72 mm
(K) Fork Offset	50 mm	50 mm	45 mm	45 mm	45 mm
(L) Stack	478 mm	505 mm	522 mm	546 mm	572 mm
(M) Reach	379 mm	387 mm	404 mm	425 mm	445 mm
(O) Crank Length	165 mm	165 mm	170 mm	170 mm	172.5 mm
